Raptor-500
Automatic Laser Cleaning Equipment
Product Details
● No damage cleaning with high precision and high efficiency
● On-line automatic cleaning is available
● Mute water cooling system
● Long working distance {up to 250nm)
● Average power (up to 500W)
● Laser Class IV
Parameter

System features:
• Pulsed fiber laser
• Working distance can be up to 250mm
• Average laser power 500w
• Suitable for robots
• Cleaning efficiency:30ma/hour

Size (h x w x d) [mm³] Approx.1460x1020x780
Weight (approx.) [kg] 150
Cooling system

internal water cooling system

Laser power [W] 500
Wavelength [nm] 1064
Power supply (incl. quick charger) 24V DC / 220V AC
Maximal power consumption [W] 2000
Min / Max ambient temperature [°C] 5-40
Humidity [%] 10-95
Laser class IV
